OPTOKON

Intel® Xeon® Processor
64 GB DDR4 Memory
6x 1G routed server ports
USB, RS-232 serial ports

The OPTOKON compact ultra-durable server LMCP-7H is equipped with Intel® CPU, M2 on board disc, one removable SSD disc and up to 6 routed Gigabit Ethernet ports. The LMCP-7H supports up to 64 GB of DDR4 memory, resulting in a reduction in overall power consumption compared to DDR3-based servers.
The LMCP-7H offers military grade features in rugged box making it an ideal platform for applications in harsh and rugged environments. LMCP-7H can operate in harsh environment under temperature range from -32 to 75°C, sealed against dust and debris, our Rugged Line stands up to shock, vibration and extreme temperatures.

OPTOKON NATO supplier code: 1583G

The OPTOKON introduces the LMCP-28H-NG new generation of highly versatile mobile computing platform which delivers a powerful and rugged network router, network switch, server and VoIP call manager in a single low-SWaP device. As the center of the mobile data network, it provides an integrated and versatile communications server for military, public safety, C4ISR and other network-centric communications systems.
The system is equipped with power full Intel® Xeon® processor which delivers exceptional value and unmatched performance density per watt in an SoC package, high capacity RAM, two removable Storage disc SSD and wide range of connection ports, both fiber optic and copper wires. The LMCP is available in rugged boxes to fill all demands on communication system used in harsh environmental conditions. Fiber optic ports are equipped with rugged HMA connectors operated according to Expanded Beam technology, which allows to use all advantages of highspeed data transmission in field conditions.

OPTOKON NATO supplier code: 1583G

LMCP Multi Full I/O Cable
LMCP Management Cable
Cable LMCP CANbus


LMCAB series introduces Expansion cable accessory designed for high speed data transmission in industrial or military environments. This data cable meets the requirements of Standards EIA/TIA-568B and is equipped with ruggedized connector on the server side and industrial IP65 connectors on the peripheral side.


A 4 pair, SFTP round patch cable, designed to fill the ISO / IEC 11801 Category 5e/6 requirements (cat 5e on 76 m). The cable contains 4 twisted pairs, cabled, double shielded with kevlar reinforcement strands, jacketed in black UV resistant Polyurethane HFFR. Designed for fixed or portable applications in harsh environments.

LMCAB series introduce Ethernet Category 5e patchcords designed for high speed data transmission in industrial or military environments. This data cable meets the requirements of Standards EIA/TIA-568B and is and is equipped with ruggedized connector RJF6MG type.

Proven Cisco technology
Five programmable line keys
Encrypted voice communications
Widescreen VGA backlight color display

The OPTOKON LMIPT-41 is a rugged IP phone specifically designed for use in harsh environmental conditions. The IP phone delivers the latest technology and advancements in IP telephony based on the Cisco 8841 platform and provides communication over the same data network as your computer, allowing you to place and receive phone calls, put calls on hold, transfer calls, make conference calls, etc. The OPTOKON LMIPT-41 is built into a fully sealed and vibration proof aluminum chassis. The phone in a ruggedized version enables the use of all the functionality of the Cisco technology in harsh environmental operating conditions.

The LMIPT-41 offers five programmable line keys. The keys can be configured to support either multiple directory numbers or call features such as speed dial. Productivity can be boosted by handling multiple calls for each directory number, using the multi call-per-line feature. Fixed function keys provide one-touch access to applications, messaging, the directory, as well as regular call features such as hold/resume, transfer, and conference. The backlight acoustic keys provide flexibility for audio path selection and switching.

OPTOKON LMAT-116N is a rugged analog phone specially designed for use in harsh environmental conditions. The phone offers an easy-to-use interface and provides a traditional telephony user experience.

Ruggedized 1/10 Gigabit
Ethernet Layer 2/3 Managed PoE Switch
2x 1/10G WAN, FO HMA or RJ-45
8 or 24x LAN 10/100/1000Base-T, PoE

The OPTOKON® LMSW-E33 ruggedized switch based on Cisco® Embedded Service Switch (ESS) 3300 extends switching capabilities to mobile and embedded networks that operate in extreme environments. The flexible, compact form factor of the switch, powered by Cisco IOS® Software, provides highly secure data, voice, and video communications to stationary and mobile network nodes, making it ideal for use in harsh environmental conditions. 10G fiber optic ports are terminated with HMA “Expanded Beam” connectors, which allows interconnection of the nodes of tactical network by the help of cables with optical fibers. The used “Expanded Beam” technology preservers all advantages of signals transmission through the optical lines in field harsh environmental conditions.
The switch supports a variety of management functions, including Web UI, MIB, SmartPort, SNMP, syslog, DHCP server, SPAN session
The switch is able to fit all the common 24 V DC power systems. The switch operates in wide operating temperature range -40 to +70°C. The switch can operate as standalone device or in addition the 19” brackets allow switch installation into 19” rack. Two switches can be connected on the side and mounted in a 19 "rack.

OPTOKON NATO supplier code: 1583G

3x 100/1000Base-X FO HMA
8x 10/100/1000Base-T, RJ-45 with PoE+

The LMSW-83M is Layer 2 military grade managed switch with 3x Fiber optic HMA-J ports (Gigabit or Fast Ethernet) and 8x 10/100/1000Base-X RJ-45 ports with PoE+ functionality that provides stable and reliable Ethernet transmission. The LMSW-M series models can provide excellent data optical network performance and rugged design.
The switch supports a variety of management functions, including STP/RSTP/MSTP and ITU-T G.8032 Ring<50 ms recovery time, advanced PoE management functions such as PoE device auto-checking and auto reset, layer 2 Ethernet IGMP, VLAN, QoS, Security, IPv6, bandwidth control, port mirroring, cable diagnostic and Green Ethernet.
The switch is able to fit all the common 12/24 V DC and 230 V AC power systems simultaneously (redundant power supply). The switch operates in wide operating temperature range -40 to +70 °C. The switch can operate as stand alone device or in addition the 19” brackets allow switch installation into 19” rack.

OPTOKON NATO supplier code: 1583G

OPTOKON NATO supplier code: 1583G

8x 10/100/1000Base-T, RJ-45 with PoE+
The LMSW-80MD is a ruggedized field switch, which has been developed according to the requirements for optical networks in harsh environmental conditions. It is designed for operation in military tactical networks, for installation in heavy industry enterprise, oil refineries and mining plants, or for rescue actions during natural disasters. The switch combines all advantages: excellent data network performance and rugged design.
The Gigabit Ethernet LMSW-80MD switch includes 8x RJ-45 LAN ports. The switch supports a variety of management functions, including STP/RSTP/MSTP and ITU-T G.8032 Ring<50 ms recovery time, advanced PoE management functions, layer 2 Ethernet IGMP, VLAN, QoS, Security, IPv6, bandwidth control, port mirroring, cable diagnostic and Green Ethernet.
The switch is able to fit all the common 24 V DC power systems simultaneously (redundant power supply). The switch operates in wide operating temperature range -40 to +70 °C. The switch can operate as stand alone device or in addition the 19” brackets allow switch installation into 19” rack.


LMSW-E1
Ruggedized Ethernet Layer 2 Managed Switch
2x 1G WAN, FO HMA or RJ-45
4x LAN 10/100BASE-T with PoE/PoE+
The OPTOKON^® LMSW-E1 ruggedized switch based on Cisco^® technology extends switching capabilities to mobile and embedded networks that operate in extreme environments. It is an attractive entry level product as a GUI-based, lightly-managed switch. The IE 1000 is a good fit for locations with harsh temperatures and small spaces and is Power over Ethernet (PoE) capable with zero IT management.  The switch is able to fit all the common 24 V DC power systems. The switch operates in wide operating temperature range -40 to +60°C.


The OPTOKON® LMSW-E2U ruggedized switch based on Cisco® technology extends switching capabilities to mobile and embedded networks that operate in extreme environments. The flexible, compact form factor of the switch, powered by advanced Cisco IOS® Software, provides highly secure data, voice, and video communications to stationary and mobile network nodes, making it ideal for use in harsh environmental conditions.
The switch is able to fit all the common 24 V DC power systems. The switch operates in wide operating temperature range -40 to +75°C.

OPTOKON NATO supplier code: 1583G

OPTOKON NATO supplier code: 1583G
The LMSW-42 is a low cost ruggedized field switch with 2 fiber optic ports and 4 RJ-45 ports.  High Power PoE ruggedized switch is specifically designed to meet IEEE 802.3af/at standards for powering network devices with up to 30 W output per PoE port. With PoE function, it becomes simplified to install network devices such as IP phones, IP surveillance cameras, wireless access points, and other PoE enabled devices in outdoor or remote areas where are hard-to-reach power source.
The LMSW-42 switch supports 4-port Power-over-Ethernet on ports 1 to 4 and 2-port 100/1000Base-X optical fiber. The switch is classified as power source equipment (PSE) can be used to power IEEE 802.3af/at standard devices (PD), eliminating the need of additional power cable wiring. This PoE switch supports IEEE 802.3/802.3u/802.3x/802.3ab with 10/100/1000M, full/half-duplex, MDI/MDI-X auto-sensing to provide an economical high-bandwidth solution for your ruggedized Ethernet network.


OPTOKON NATO supplier code: 1583G
The LMSW-42M(P) is a small version of ruggedized field switch, which has been developed according to the requirements for optical networks in harsh environmental conditions. It is designed for operation in military tactical networks, for installation in heavy industry enterprise, oil refineries and mining plants, or for rescue actions during natural disasters. The switch combines all advantages: excellent optical network performance and rugged construction.
The Gigabit Ethernet LMSW-42M(P) switch includes 4x RJ-45 LAN ports and 2x optical fiber ports. The switch supports a variety of management functions, including STP/RSTP/MSTP and ITU-T G.8032 Ring<50 ms recovery time, advanced PoE management functions such as PoE device auto-checking and auto reset, layer 2 Ethernet IGMP, VLAN, QoS, Security, IPv6, bandwidth control, port mirroring, cable diagnostic and Green Ethernet.
The switch is classified as power source equipment (PSE) and can be used to power IEEE 802.3af/at standard devices (PD), eliminating the need of additional power cable wiring. The switch operates in wide operating temperature range -40 to +75 °C.

Input: 22 – 29 V DC
Output: 24 V DC, 15 A

The LMUPS-80 Series is a high efficiency, DC power supply and battery charger that brings sophisticated features into a ruggedized design. The LMUPS-80 allows the battery charge to be regulated independently from the DC outputs, meaning that the battery will always receive the optimal charging current without the load being affected. Intelligent 3-stage charging will bring a battery back to a full state of charge much faster than trickle or float charging can.  Through the Battery-Parameter software adjustments at the UPS can be done via PC.

OPTOKON NATO supplier code: 1583G


The LMC series introduces the media converter housed in a robust metal box. It provides Expanded Beam connectors for fiber optic cable and copper twisted pairs ports for harsh environmental conditions. The LMC rugged design extends the use of Ethernet in harsh environmental conditions – heavy industry, petrochemical, mines, broadcasting and other field applications. It meets the demands for mobility, easy installation and the mechanical resistance necessary for deployment in the field. The LMC converters give you the freedom to extend your 10/100/1000 Mbps cabling distance by allowing connectivity up to 2 km over MM fiber, up to 50 kilometers if use the SM fiber. LED indicators show the power status of the converter, LAN port and fiber activity.
The basic LMC-01.GF configuration includes the media converter in ruggedized box. The optical and electrical ports converters are terminated at separate connectors, HMA type for FO, rugged RJ-45 for copper LAN interface. Power supply is ensured via 3-pins rugged connector and/or PoE (PD – powered device) via LAN cable.

The LMC series introduces the media converter housed in a robust metal box. It provides Expanded Beam connectors for fiber optic cable and copper twisted pairs ports for harsh environmental conditions. The LMC rugged design extends the use of Ethernet in harsh environmental conditions – heavy industry, petrochemical, mines, broadcasting and other field applications. It meets the demands for mobility, easy installation and the mechanical resistance necessary for deployment in the field. The LMC converters give you the freedom to extend your 10/100/1000 Mbps cabling distance by allowing connectivity up to 2 km over MM fiber, up to 50 kilometers if use the SM fiber. LED indicators show the power status of the converter, LAN port and fiber activity.
The basic LMC-01.BF configuration includes the media converter in ruggedized box. Data transmission and power supply are ensured via separate ruggedized connectors, copper wires cables might be ordered as accessories.


The LMC series introduces the media converter housed in a robust metal box. It provides Expanded Beam connectors for fiber optic cable and copper twisted pairs ports for harsh environmental conditions. The LMC rugged design extends the use of Ethernet in harsh environmental conditions – heavy industry, petrochemical, mines, broadcasting and other field applications. It meets the demands for mobility, easy installation and the mechanical resistance necessary for deployment in the field. The LMC converters give you the freedom to extend your 10/100/1000 Mbps cabling distance by allowing connectivity up to 2 km over MM fiber, up to 50 kilometers if use the SM fiber. LED indicators show the power status of the converter, LAN port and fiber activity.
The basic LMC-02.GC configuration includes two media converters in ruggedized box. The optical and electrical ports converters are terminated at separate connectors, HMA type for FO, rugged RJ-45 for copper LAN interface. Power supply for both is ensured via 3-pins rugged connector.


The LMC series introduces the media converter housed in a robust metal box. It provides Expanded Beam connectors for fiber optic cable and copper twisted pairs ports for harsh environmental conditions. The LMC rugged design extends the use of Ethernet in harsh environmental conditions – heavy industry, petrochemical, mines, broadcasting and other field applications. It meets the demands for mobility, easy installation and the mechanical resistance necessary for deployment in the field. The LMC converters give you the freedom to extend your 10/100/1000 Mbps cabling distance by allowing connectivity up to 2 km over MM fiber, up to 50 kilometers if use the SM fiber. LED indicators show the power status of the converter, LAN port and fiber activity.
The basic LMC-01.GC configuration includes the media converter in ruggedized box. The optical and electrical ports converters are terminated at separate connectors, HMA type for FO, rugged RJ-45 for copper LAN interface. Power supply is ensured via 3-pins rugged connector, from data cable PoE – PD powered device or from USB port.

The LMC series introduces the media converter housed in a robust metal box. It provides Expanded Beam connectors for fiber optic cable and copper twisted pairs ports for harsh environmental conditions. The LMC rugged design extends the use of Ethernet in harsh environmental conditions – heavy industry, petrochemical, mines, broadcasting and other field applications. It meets the demands for mobility, easy installation and the mechanical resistance necessary for deployment in the field. The LMC converters give you the freedom to extend your 10/100/1000 Mbps cabling distance by allowing connectivity up to 2 km over MM fiber, up to 50 kilometers if use the SM fiber. LED indicators show the power status of the converter, LAN port and fiber activity.
The basic LMC-01.BC configuration includes the media converter in ruggedized box. Data transmission and power supply are ensured via the same connectors, PoE (PD – powered device) or unused wires in data cable. Optical and copper wires cables might be ordered as accessories.


The LMC series introduces the media converter housed in a robust metal box. It provides Expanded Beam connectors for fiber optic cable and copper twisted pairs ports for harsh environmental conditions. The LMC rugged design extends the use of Ethernet in harsh environmental conditions – heavy industry, petrochemical, mines, broadcasting and other field applications. It meets the demands for mobility, easy installation and the mechanical resistance necessary for deployment in the field. The LMC converters give you the freedom to extend your 10/100/1000 Mbps cabling distance by allowing connectivity up to 2 km over MM fiber, up to 50 kilometers if use the SM fiber. LED indicators show the power status of the converter, LAN port and fiber activity.
The basic LMC-02.GF configuration includes two independent media converters in one box. The optical and electrical ports of both converters are terminated at separate connectors, HMA type for FO, rugged RJ-45 for copper LAN interface. Power supply for both converters is ensured via one connector.


The OPTOKON LMES power supply contains an AC/DC converter and a distribution box for eight appliances with 8 fuses that also serve to switch the power output for the connected devices. Depending on the selected current combination of the breaker elements and output connectors, a total supply current of up to 20 A can be distributed.
The output connectors are of the D38999 standard, the same type used in other OPTOKON ruggedized devices.
The switching on of the protected branch is indicated, in addition to the position of the circuit breaker, by a green LED. The output voltage value can be checked on the front panel display.
The 19" rack width aluminium box is based on the OPTOKON LMSW-80 switch series, with a box height of 3U.


The LMSB-14.1G introduces a switchboard, it might be used as analog VoIP gateway, VoIP (ISDN) PBX or voice & data router. The ruggedized design allows the use in harsh environmental conditions. It offers FXS ports for analogue phone sets, FXO ports for connection to PBX lines, E&M interfaces for cooperation with radio systems and E1 digital line. The LMSB-14.1G gateway can be connected to tactical network via 100 Mbps Ethernet line or via up-link port based on optical fibers cable, which is equipped with HMA Expanded Beam connector.  Four channels GSM module available on request. Power supplying of LMSB-14.1G can be ensured from any DC source 10.5 – 36 V. The LMSB-14.1 switchboard can be mounted into vehicle as well as deployed on stationary workstation.
OPTOKON NATO supplier code: 1583G

FOTAS SF-10 is an acoustic sensor based on fiber optic infrastructure and It can be easily distributed in variant terrains. SF-10 keeps your perimeter and borders safe and sends you early threat warnings.
Laser beams sent by the laser source traveling the entire system. Providing information while flowing through the fiber optic cable. When laser beams come back to the FOTAS, a computer software analyse them. Noises and unrelated data eliminated through the software. Finally FOTAS AI classifies the alarms.
Actions that create vibration can be watched live on the system. Noisy areas can be isolated and deactivated at the request of user. All alarms received and reported over the web interface. They are stored and can be exported.
It is one of the proven early warning security system. FOTAS detects third-party intervention, illegal crossing attempts and unauthorized excavations along a line spanning several kilometres to thousands of kilometres.

Ruggedized next Gen Gigabit Router
2x GE WAN + 4x GE LAN ports, PoE

The OPTOKON LMSR-R63 ruggedized router based on Cisco Next Gen GE Embedded Router 6300 is optimized for military networks that require IP routing and services. The compact router provides highly secure data, voice, and video communications to stationary and operational tactical network nodes.
The LMSR-R63 is a high-performance, ruggedized router designed for use in harsh environments—offering reliable operation in extreme temperatures and under shock and vibration conditions typical for mobile applications in rugged terrain. With onboard hardware encryption, the router offloads encryption processing from the routing engine to provide highly secure yet scalable video, voice, and data services for mobile and embedded outdoor networks. The router offers high performance, six Gigabit Ethernet interfaces (two routed and four switched), and a rich Cisco IOS Software feature set, providing investment protection for customers deploying bandwidth-intensive applications in mobile or embedded networks in heavy industrial, public safety, transportation, defense, and energy markets.
The router supports a variety of management functions, including Cisco DNA, Web UI, IOx, MIB – SNMP (version 2 and 3), syslog etc. It is able to fit all the common 24 V DC power systems. The router operates in wide operating temperature range -40 to +70 °C and can operate as a stand alone device or it can be installed into 19” rack.

Outdoor Sensitive Star Detection Cable
Rev. 0280-22/36
Special fiber optic cable for Acoustic Sensing System. Suitable for installation on the fence and directly into the ground.

Designed for FOTAS, for perimeter security


The OPTOKON introduces the LMCP-28H-NGe1 improved generation of highly versatile mobile computing platform which delivers a powerful and rugged network router, network switch, server and VoIP call manager in a single low-SWaP device. As the center of the mobile data network, it provides an integrated and versatile communications server for military, public safety, C4ISR and other network-centric communications systems.
The system is equipped with power full Intel® Xeon® processor which delivers exceptional value and unmatched performance density per watt in an SoC package, high capacity RAM, two removable Storage disc SSD and wide range of connection ports, both fiber optic and copper wires. The LMCP is available in rugged box to fill all demands on communication system used in harsh environmental conditions. Fiber optic ports is equipped with rugged HMA connectors operated according to Expanded Beam technology, which allows to use all advantages of highspeed data transmission in field conditions.


LMSW-E33
Ruggedized Gigabit
Ethernet Layer 2/3 Managed PoE Switch
2x 1G WAN, FO HMA or RJ-45
8x LAN 10/100/1000Base-T, PoE

The LMSW-E33 ruggedized switch is designed for extreme environments, ensuring secure and reliable communication for mobile and stationary networks. Its compact design and advanced software support make it suitable for various demanding applications.

OPTOKON NATO supplier code: 1583G

The LMC series introduces the media converter housed in a robust metal box. It provides Expanded Beam connectors for fiber optic cable and copper twisted pairs ports for harsh environmental conditions. The LMC rugged design extends the use of Ethernet in harsh environmental conditions – heavy industry, petrochemical, mines, broadcasting and other field applications. It meets the demands for mobility, easy installation and the mechanical resistance necessary for deployment in the field. The LMC converters give you the freedom to extend your 10/100/1000 Mbps cabling distance by allowing connectivity up to 2 km over MM fiber, up to 10 kilometers if use the SM fiber. LED indicators show the power status of the converter, LAN port and fiber activity.

The basic LMC-01.GCS configuration includes the media converter in ruggedized box. The optical and electrical ports are terminated at rugged connectors, HMA type for FO, rugged D38999 18-pins for LAN interface and power supply.
